Easy Gripper 2800-3.2T
Professional tools for handling of OTR/EM tyres up to 27.00R49
Ideal for:
Tyre Service
Open Pit Mines & Quarries
Civil Construction / Cement Plants
Tyre Manufacturers / Dealers
OEM / Workshops / Assembly Lines
Unique 3-point grip
Precise rotation +/-25°
35° or 90° tilt, Horizontal to vertical
Tools for safe handling of tyre rings
Integrated camera system for optimal view
Prevent damage to tyres, rims & equipment
Customization on request
Save time. Improve safety.
Easy Gripper
The Easy Gripper product range is designed to help professional tyre technicians in a multitude of conditions and situations. Implementing The Easy Gripper makes tyre handling faster and safer, while preventing damages to tyres, rims and equipment.
Capability
With a gripping range of Ø1.150 - 2.800 mm (45 - 110”) and a lifting capacity of 3.2 ton (7.000 lbs) at a CoG of 650 mm (25,6”), the Easy Gripper 2800-3.2T handles large OTR/EM tyres and wheels up to 27.00R49.
Use on Forklifts, Front loaders, Telehandlers and Truck cranes
The Easy Gripper 2800-3.2T with the 90° tilt module, is ideal for use on forklifts.
The Easy Gripper 2800-3.2T Compact without tilt or with the 35° tilt module is a good choice depending on the tilt provided by the carrier.
By use of our Crane Module, the Gripper can also fit with almost any truck crane system.
Standard features
Unique and safe 3-point grip
Prevents accidents.
Prevents deformation of tyres.
Prevents damages to tyres, rims and equipment.
Integrated camera system with 2 cameras
For optimal view and for precise hub and bolt alignment.
With automatic IR function in insufficient lighting conditions.
Precise rotation +/-25°
35° or 90° tilt module, horizontal to vertical
LED working light
Customized attachment system
Optional accessories
Quick Shift System
Easy hook on and off.
Shift between Gripper and forks.Easy shift of gripping pipes for various purposes
Telescopic pipes for long reach, to provide room for the tyre technicians and for dual tyre handling.
Flat top arm for limited tyre clearanceTools for safe handling of tyre rings
Special designed Ring Handling Tools for handling multi-piece rim wheels are another exclusive feature that is only available with an Easy Gripper.
With the Ring Handling Tools the tyre technicians can grip, hold, press, or place tyres, rims and rings as needed- a major improvement of safety and efficiency!
Customization on request
Video
Downloads
Contact us
Improve safety and efficiency
The unique 3-point grip, precise tilt and rotation, integrated camera system and special designed Ring Handling Tools all improves the safety as well as the efficiency while handling tyres and wheels.
Optimized tyre logistics
Stacks tyres both horizontal and vertically at workshops and warehouse areas. Fast and safe loading and unloading of trailers.
Mobile and on-site tyre service
Mounted on forklifts, front loaders or telehandlers all tyre service situations in all environments can be handled in the mining industry and civil construction.
OEM assembly lines
The Easy Gripper has full control of the tyres and wheels during the whole process, until it is firmly mounted on a vehicle. Proven record of reducing internal damages with up to 90%.
“The safety the Easy Gripper delivers has no comparison. Having 3 grip points generates a stability that is not found in other manipulators!”
“Thanks to the Easy Gripper, we can change and repair large industrial tyres even faster and safer, because time is money!”
Technical specifications
Technical Data
Weight: Compact = 2.050 kg / 35°= 2.150 kg / 90°= 2.355 kg
Lifting capacity:
3.200 kg (7.000 lbs) at (C) from (B) 650 mm (25,6”)
2.600 kg (5.720 lbs) at (D) from (B) 1.300 mm (51”)
Tyre diameter: 1.150 - 2.800 mm (45-110”)
Standard pipes: Ø160 x 900 mm (6,3 x 35”)
Telescopic pipes: Ø220 x 1.050 -> 1.700 mm (8,7 x 41 -> 67”)
Attachment: ISO/FEM/ITA Class 4 or 5 / Terminal West / Loader specific
Technical Requirements
Lifting capacity: Individual calculation
Electrical supply: 12/24 V / min 10A
Hydraulic: 1 double acting hydraulic valve
Pressure min-max: 150 - 250 bar (2.175 - 3.626 psi)
Return pressure: max. 10 bar (145 psi)
Flow: max. 75 l/min. (19,8 gal/min.)
Explanatory description
(A) CoG Gripper = 700 mm (28”)
(B) Face of Gripper = 945 mm (37”)
(C) CoG Load1 = 1.600 mm (63”)
(D) CoG Load2 = 2.245 mm (88”)
Explanatory description
(A) CoG Gripper = 800 mm (32”)
(B) Face of Gripper = 980 mm (39”)
(C) CoG Load1 = 1.630 mm (64”)
(D) CoG Load2 = 2.280 mm (90”)
Explanatory description
(A) CoG Gripper = 1.170 mm (46”)
(B) Face of Gripper = 1.400 mm (55”)
(C) CoG Load1 = 2.050 mm (81”)
(D) CoG Load2 = 2.700 mm (106”)
Supporting tools and accessories
Even though the Easy Gripper is an incredible tyre handler / tyre manipulator, it can not do the entire tyre service job on it’s own. Therefore, we offer you following high-quality tools and accessories to support other parts of the tyre service processes.
